| wire rolling machine is a rolling equipment which processes copper, aluminum, stainless steel, carbon steel, alloy and other materials into flat, square, semi-circular and triangular wires by cold rolling. The design team of Zegota technology Co., Ltd. is based on 30 years of R&D and design experience, and has complete independent intellectual property rights. The product matches the international first-line brand and its performance is at the advanced level of the industry. With flat roll, vertical roll, symmetrical four-roll, universal roll and other rolling heads, we can design multi-pass rolling mill production line according to customer's product requirements. It can not only greatly improve the production efficiency of the industry, but also improve the quality of products. It is the best choice for rolling mills to gradually replace the cold drawing and drawing process equipment. | ||
| Item | Parameter | |
| compostion | Raw material diameter | Φ0.1~Φ20mm |
| Raw material | Cooper, Stainless steel, Carbon steel, Steel alloy etc. | |
| Rolled wire size | Max. width-thickness ratio: 30 | |
| Final precision | ≤0.005mm | |
| Working speed | 10~600m/min | |
| Payoff | Per raw material wire. | |
| Tension | Pneumatic adjustable, servo torque control. | |
| Roller | Per rolling method. | |
| Inline detection | Real-time Width and Thickness Detection. | |
| Cooling system | Cooling medium constant temperature control, precision filtration. | |
| Lubrication system | Centralized lubrication and constant temperature control. | |
| Straightener | Vertical straightening and Horizontal Straightening. | |
| Degreasing system | Air knife oil removal/scraping oil removal. | |
| Take up | Precision take-up, layout accuracy 0.2m, I-wheel can be customized. | |
